Supercharger System Upgrade Kit PN: 15883
Availability:
Out-of-Stock
Description
Owners of 2018-2020 Ford Mustangs who have installed an Edelbrock PN: 15832/158320 Stage I Supercharger Kit can now step up to the next level of performance with the Stage II Supercharger System Upgrade Kit PN: 15883. With this Stage II upgrade kit, your vehicle remains emissions-legal in all 50-states while taking full advantage of the improved Gen 3 DI/PI Coyote engine. The Edelbrock Stage II Supercharger Upgrade Kit features all of the vital components required to support the additional horsepower increase that makes this our highest rated horsepower system. Included are a 103mm Throttle Body to replace the Stage I 80mm, a high-flow air intake system, a 113mm Mass Airflow Sensor Kit with injection-molded housing, larger 50 lb/hr direct-port fuel injectors along with a Fuel Pump Voltage Regulator, and an 8-rib belt drive to minimize slippage and maintain consistent boost pressure under full throttle.
Supercharger System Upgrade Kit PN: 15883 - Part number: EDL-15883 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 15883 - Supercharger System Upgrade Kit PN: 15883 supercharger-upgrade-kit
Data sheet
- Finish
- Black
- Mounting Hardware Included
- Yes
- Maximum Horsepower
- 686RW
- Gasket Or Seal Included
- Yes
- Fuel Injector Type
- 50 4U
- System Type
- Stage 2 - Street/Strip System
- Mounting Bracket Included
- Yes
- Universal Or Specific Fit
- Specific
- Quantity
- Kit
- CARB Executive Order Number
- D-215-115
- Air Filter Included
- Yes
- Calibration
- Yes
- Maximum Boost Pressure
- 13 PS
- Maximum Torque
- 533RW 85
- Outside Pulley Diameter
- 3.5 IN
- Pulley Belt Width
- 8-Rib
- Rotor Type
- Eaton TVS 2650
- Tensioner Included
- Yes
- Harmonic Balancer Diameter
- 7.75 IN
- Pulley Groove Quantity
- 8-Rib
- Pulley Color
- Black Anodized
- Pulley Material
- Aluminum
Package dimensions
Width: 44.00 inch
Height: 26.00 inch
Depth: 44.00 inch
Weight: 50.00 lb
