Stg 2 Supercharger PN: 158390 for Mustang
Availability:
Out-of-Stock
Description
Take your 2015-17 Mustang to the next level with the Edelbrock Stage 2 Supercharger System W/O TUNERR PN: 158390 for the Gen 2 Ford 5.0L Coyote engine. This potent new kit adds huge gains in horsepower and torque over Stage 1 performance, all while maintaining emissions-legal status in all 50 states. At the heart of this system is the top-of-the-line R2650 TVS rotor assembly housed with an integrated high-capacity DP3C (dual-pass, three-core) air-to-water intercooler that lowers incoming air temperatures and increases power potential. To support the additional Stage 2 power increase, the fuel system components are upgraded to include larger 78 lb/hr direct-port injectors along with a drop-in 400 LPH fuel pump assembly with internal check valve. A dramatic increase in airflow over the Stage 1 kit comes from a new 103mm billet aluminum throttle body and high-flow air intake system with 113mm MAF housing. Like our Stage 1 kit for the Mustang, the Stage 2 System installs cleanly with no modifications to the hood or body and comes complete with all hardware, hoses and a handy full-color step-by-step instruction manual to streamline the installation process. This kit is backed by Edelbrock's industry-leading 3-Year/36,000-mile Powertrain Warranty. For the same kit with tuner, order PN: 15839.
Stg 2 Supercharger PN: 158390 for Mustang - Part number: EDL-158390 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 158390 - Stg 2 Supercharger PN: 158390 for Mustang supercharger-kit
Data sheet
- Finish
- Black Powder Coated
- Mounting Hardware Included
- Yes
- Gasket Or Seal Included
- Yes
- Fuel Injector Type
- 78 4U
- System Type
- Stage 2 - Street/Strip System
- Mounting Bracket Included
- Yes
- Universal Or Specific Fit
- Specific
- Housing Material
- Cast Aluminum
- Quantity
- Kit
- Vehicle Model
- Mustang
- CARB Executive Order Number
- D-215-107
- Air Filter Included
- Yes
- Calibration
- No
- Center Housing Cooling Type
- Intercooler
- Fuel Pump Included
- Yes
- Hose Included
- Yes
- Internal Step Up
- Yes
- Oil Capacity
- 150 ML
- Outside Pulley Diameter
- 3.25 IN
- Pulley Belt Width
- 6-Rib
- Rotor Type
- Eaton TVS 2650
- Harmonic Balancer Diameter
- 6.67 IN
- Spark Plugs Included
- Yes
Package dimensions
Width: 44.00 inch
Height: 26.00 inch
Depth: 44.00 inch
Weight: 178.00 lb
