SC PRO TUNER SYSTEM CHRYSLER 2015-17 R2650 DP3C 5.7L V8 HEMI LX/LC NO TUNER
Availability:
Out-of-Stock
Description
The Edelbrock supercharger System part PN: 15171 includes all of the essential components that a racer would need to build a custom supercharged racing setup for their Chrysler 5.7L HEMI engine. They offer flexibility in pulley selection, cold air intake and more. These systems are for competition racing use only. Features a unique design with minimal components and fits under the stock hood. The core of this system is the Eaton Gen VI R2650 TVS rotating assembly with a four-lobe design with 170 degrees of twist for maximum flow, minimum temperature rise. Our unique and efficient inlet configuration results in a shorter, less restrictive intake path for improved airflow, without the need for a jack-shaft. Keeping the air cool is a high-capacity air-to-water intercooler and low-temp heat exchanger. NO HANDHELD PROGRAMMER INCLUDEDwill require custom tuning.
Chrysler:Gen III HEMI:345 (5.7L)
Chrysler:Gen III HEMI:345 (5.7L)
SC PRO TUNER SYSTEM CHRYSLER 2015-17 R2650 DP3C 5.7L V8 HEMI LX/LC NO TUNER - Part number: EDL-15171 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 15171 - SC PRO TUNER SYSTEM CHRYSLER 2015-17 R2650 DP3C 5.7L V8 HEMI LX/LC NO TUNER supercharger-kit
Data sheet
- Finish
- Black Powder Coated
- Mounting Hardware Included
- Yes
- Gasket Or Seal Included
- Yes
- System Type
- Pro-Tuner Racing System
- Mounting Bracket Included
- Yes
- Universal Or Specific Fit
- Specific
- Housing Material
- Cast Aluminum
- Quantity
- Kit
- Vehicle Model
- Charger
- Calibration
- No
- Center Housing Cooling Type
- Intercooler
- Hose Included
- Yes
- Internal Step Up
- Yes
- Oil Capacity
- 150 ML
- Rotor Type
- Eaton TVS 2650
- Tensioner Included
- Yes
Package dimensions
Width: 23.94 inch
Height: 18.00 inch
Depth: 32.44 inch
Weight: 134.00 lb
