Steering Tie Rod End

Data sheet

Feature 1

Problem Solver® powdered metal gusher bearing design enables grease to flow through the bearing to the stud for reduced friction and enhanced strength and stability.

Feature 2

Cover plate design allows for tighter tolerances vs traditional cover plate designs, providing a more durable and etended life part.

Feature 3

Belleville washer preload provides lower torque and stud articulation with minimal aial clearance.

Feature 4

Full ball metal stud provides 360 degrees of smooth, consistent, rotational movement resulting in more responsive steering.

Feature 5

Greaseable socket design allows new lubricant to flush contaminants from the assembly, reducing corrosion and wear.

Stud Diameter Dimension (bottom in.)

0.748

Stud Diameter Dimension (top in.)

0.629

Length (in)

50.905
