19X26 GM DP RAD
Availability:
Out-of-Stock
Description
Radiator, Aluminum, Crossflow, 26 in. Width, 19 in. Height, 3.125 in. Thick, Each
We've seen too many race engines destroyed before their time because of insufficient cooling. That's why we've created our own Summit brand of racing radiators to handle the special cooling needs of race engines. Summit universal fit race radiators are available in 1-row, 2-row, or 3-row designs with high-capacity 1 in. tubing to out-cool common 4-row copper-brass radiators. We also gave the radiators furnace-brazed, all-aluminum construction with aluminum water tanks, tubes, fins, and headers for reduced weight. On top of that, they include a heavy-duty machined filler neck. If your stock mounts won't fit, we offer a set of universal mounting brackets designed to fit these radiators.
We've seen too many race engines destroyed before their time because of insufficient cooling. That's why we've created our own Summit brand of racing radiators to handle the special cooling needs of race engines. Summit universal fit race radiators are available in 1-row, 2-row, or 3-row designs with high-capacity 1 in. tubing to out-cool common 4-row copper-brass radiators. We also gave the radiators furnace-brazed, all-aluminum construction with aluminum water tanks, tubes, fins, and headers for reduced weight. On top of that, they include a heavy-duty machined filler neck. If your stock mounts won't fit, we offer a set of universal mounting brackets designed to fit these radiators.
19X26 GM DP RAD - Part number: SUM-380345 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 380345 - 19X26 GM DP RAD radiator
Data sheet
- Notes
- Radiator does not have a drain petcock.
- Quantity
- Sold individually.
- Row Quantity
- 2
- Tube Size
- 1 in.
- Radiator Material
- Aluminum
- Radiator Style
- Crossflow
- Transmission Cooler
- No
- Inlet Location
- Upper passenger side
- Outlet Location
- Lower passenger side
- Radiator Finish
- Natural
- Trans Cooler Adapter Fittings Included
- No
- Radiator Inlet Size
- 1.500 in.
- Radiator Outlet Size
- 1.750 in.
- Fan Included
- No
- Radiator Cap Included
- No
- Overall Height (in.)
- 19.000 in.
- Core Height (in.)
- 18.125 in.
- Overall Width (in.)
- 26.000 in.
- Core Width (in.)
- 20.750 in.
- Core Thickness (in.)
- 2.250 in.
- Overall Thickness (in.)
- 3.125 in.
Package dimensions
Width: 50.00 inch
Height: 30.00 inch
Depth: 10.00 inch
Weight: 50.00 lb
