Description
The Edelbrock part PN: 359900 Pro-Flo 4 XT EFI System for Chevrolet LS GEN III/IV engines is equipped with the latest technology and features. The EFI system comes complete with a Pro-Flo XT cathedral port black finish intake manifold and 35 Lb/Hr injectors capable of 550 HP with 58 p.s.i. fuel pressure. The new Pro-Flo 4 EFI systems feature an all-new ECU with a faster processor, a water proof design and measures half the depth of the previous ECU. It also has an upgraded Bluetooth chip that is faster, more reliable and will not drop connection. We've added more features for the advanced tuner giving you control over air-fuel ratios, ignition curve, idle speed, acceleration fuel, coolant fans, Rev limiter while retaining the simplicity Pro-Flo is known for. The key to the system is our exclusive E-Tuner 4 app with dyno developed base calibrations. The E-Tuner 4 app uses a Bluetooth wireless connection to communicate with the ECU's self-learning capability to continually adjust the calibration to get the maximize performance of your engine. E-Tuner 4 features a simple and easy to use setup wizard to help you get started as well as multiple dash displays so you can monitor your engines vitals and performance. Best of all, the E-Tuner 4 app is free and can be downloaded from the Google Play Store, allowing you to use your personal Android based smart phone or tablet. , Please Note 'Kit 357200 DOES NOT include a 7in. Android tablet'. , If you don't have a compatible device, then we also offer kits that include a 7in. Android tablet with the E-Tuner 4 app installed., Pro-Flo 4 does not require laptop tuning.
Chevrolet:Small-Block Gen IV L76:364 (6.0L)/376 (6.2L),Chevrolet:Small-Block Gen IV L92:364 (6.0L)/376 (6.2L),Chevrolet:Small-Block Gen IV L99:364 (6.0L)/376 (6.2L),Chevrolet:Small-Block Gen IV LS3:364 (6.0L)/376 (6.2L)
PRO FLO 4 XT LS3 FUEL INJECTION KIT SEQUENTIAL PORT LS3 GEN IV RECT PORT 550 HP - Part number: EDL-359900 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 359900 - PRO FLO 4 XT LS3 FUEL INJECTION KIT SEQUENTIAL PORT LS3 GEN IV RECT PORT 550 HP fuel-injection-system
Data sheet
- Engine Make/Size
- Chevy LS3
- Finish
- Satin
- Flange Type
- XT-Style
- Cylinder Head Type
- Sequential Port
- Fuel Rate
- 35 lbs./hr
- Maximum Horsepower
- 550
- Gasket Or Seal Included
- Yes
- Wiring Harness Included
- Yes
- Fuel Injector Type
- 35 lb/hr
- System Type
- XT-Style Kit
- Bore Diameter
- 90 MM
- Quantity
- Kit
- Distributor Cap Included
- Yes
- Throttle Body Type
- Single Blade
- Fuel Pressure Port
- 1/8-27 NPT
- Manifold Height
- A-10.2 in, B-10.0 in, C-16.9 in, D-3.2 in, E-15 Degrees
- Wire Harness Included
- Yes
Package dimensions
Width: 25.25 inch
Height: 10.31 inch
Depth: 30.19 inch
Weight: 42.00 lb
