HEADER STAINLESS STEEL
Availability:
Out-of-Stock
Description
Headers, Long Tube, 304 Stainless Steel, Natural, Chevy, Car, Small Block, Pair
Our Summit Performance headers are manufactured from mandrel-bent tubing for superior flow and greater horsepower. The headers feature a pressure-formed collector for a better flow rate and a jig-welded tube-to-flange plate for a perfect fit. They're made for off-road and racing use only. Unless otherwise noted, these headers are designed to fit the vehicle as it came from the manufacturer. This includes components like cylinder heads, chassis, steering, motor mounts, body mounts and bushings, etc. If your vehicle is using aftermarket components, parts from other applications, or custom-altered parts, then it is the installer's responsibility to verify fitment.
Our Summit Performance headers are manufactured from mandrel-bent tubing for superior flow and greater horsepower. The headers feature a pressure-formed collector for a better flow rate and a jig-welded tube-to-flange plate for a perfect fit. They're made for off-road and racing use only. Unless otherwise noted, these headers are designed to fit the vehicle as it came from the manufacturer. This includes components like cylinder heads, chassis, steering, motor mounts, body mounts and bushings, etc. If your vehicle is using aftermarket components, parts from other applications, or custom-altered parts, then it is the installer's responsibility to verify fitment.
HEADER STAINLESS STEEL - Part number: SUM-G9001SS - for American Cars - delivery to the UK and the EU
Manufacturer part number: G9001-SS - HEADER STAINLESS STEEL exhaust-header
Data sheet
- Gaskets Included
- Yes
- Quantity
- Sold as a pair.
- Cylinder Head Port Shape
- Oval
- Collector Diameter
- 3.000 in.
- Header Finish
- Natural
- Header Style
- Long Tube
- Collector Attachment
- 3-bolt flange
- Bolts/Studs Included
- Yes
- Special Attention
- The driver side front tube has an indentation for spark plug clearance; this is by design and has not been damaged.
- Transmission Mount Included
- No
- Catalytic Converter(s) Included
- No
- Header Material
- 304 stainless steel
- Weld-Up
- No
- Primary Tube Outside Diameter (in)
- 1 5/8 in.
- Flange Style
- Standard
- Collector Reducers Included
- Yes
- Tuned
- No
- Crossover Pipe Included
- No
- Motor Mounts Included
- No
- Flange Thickness (in.)
- 0.375 in.
- Collector Reducer Exit Diameter
- 2.500 in.
Package dimensions
Width: 40.00 inch
Height: 20.00 inch
Depth: 20.00 inch
Weight: 20.00 lb
