VALVE SPRINGS RPM SET OF 16

Manufacturer: EDELBROCK
Part number: 5825
MPN: 5825
UPC: 085347058259
Availability:
£207.55
Tax included

Qty: 19, Delivery time: 8 working days

Description

The Edelbrock PN: 5825 Replacement Sure Seat Valve Spring for Edelbrock PN: 5085, 60759, 60909, 60719, 60739, 60999, 60899 & 79899 cylinder heads are made of highest quality spring wire and precision wound to close tolerances.

VALVE SPRINGS RPM SET OF 16 - Part number: EDL-5825 - for American Cars - delivery to the UK and the EU

Manufacturer part number: 5825 - VALVE SPRINGS RPM SET OF 16 engine-valve-spring

Data sheet

Position
Exhaust or Intake
Material
Chromium Silicon
Inside Diameter
1.039 in.
Outside Diameter
1.460 IN
Spring Type
Cylindrical
Camshaft Type
Hydraulic Flat Tappet
Coil Bind Height
1.125 in.
Installed Height (in.)
1.85
Installed Pressure
128 PSI
Open Height
0.580 IN
Spring Rate (lbs./in.)
N/A
Tubing Length
339
Quantity
Set of 16
Damper Spring Included
Yes
Installed Height
1.800 IN
Open Pressure
338 P2
Springs Per Valve
Single

Package dimensions

Width: 3.50 inch
Height: 2.25 inch
Depth: 12.50 inch
Weight: 4.00 lb
