Out-of-Stock

V/S V6 4.3L

Manufacturer: EDELBROCK

Part number: 5814

MPN: 5814

UPC: 085347058143

Availability: Out-of-Stock

£64.95

Tax included

Call to check: 0044 (0) 1933 225 564

Description

The Edelbrock PN: 5814 Sure Seat Valve Spring for Chevy 4.3L 90 Deg V6 1987-95 O.E Cast iron cylinder heads are made of highest quality spring wire and precision wound to close tolerances, our Sure Seat Valve Spring sets are for use on original equipment heads when installing Edelbrock Performer-Plus camshafts. These are the same high-performance'springs used on Edelbrock Performer and RPM cylinder heads. For camshaft warranty compliance, use only the springs recommended by Edelbrock for each camshaft application.

Chevrolet:90 Deg V6:262 (4.3L)

V/S V6 4.3L - Part number: EDL-5814 - for American Cars - delivery to the UK and the EU

Manufacturer part number: 5814 - V/S V6 4.3L engine-valve-spring

Data sheet

Position: Exhaust or Intake
Material: Chromium Silicon
Inside Diameter: 0.750 IN
Outside Diameter: 1.250 IN
Spring Type: Cylindrical
Camshaft Type: Hydraulic Flat Tappet
Coil Bind Height: 1.160 IN
Installed Height (in.): 1.7
Installed Pressure: 110 PSI
Open Height: 0.490 IN
Spring Rate (lbs./in.): N/A
Tubing Length: 285
Quantity: Set of 12
Damper Spring Included: Yes
Installed Height: 1.700 IN
Open Pressure: 285 P2
Springs Per Valve: Single

Package dimensions

Width: 3.38 inch
Height: 2.25 inch
Depth: 12.25 inch
Weight: 3.25 lb
