V/S V8 396-454

Manufacturer: EDELBROCK

Part number: 5762

MPN: 5762

UPC: 085347057627

Availability: Out-of-Stock

£0.00

Tax included

Call to check: 0044 (0) 1933 225 564

Description

The Edelbrock PN: 5762 Sure Seat Valve Spring for Big-Block Chevy 396-402-427-454 V8 O.E Cast iron cylinder heads are made of highest quality spring wire and precision wound to close tolerances, our Sure Seat Valve Spring sets are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. These are the same high-performance'springs used on Edelbrock Performer and RPM cylinder heads. For camshaft warranty compliance, use only the springs recommended by Edelbrock for each camshaft application.

Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L)

V/S V8 396-454 - Part number: EDL-5762 - for American Cars - delivery to the UK and the EU

Manufacturer part number: 5762 - V/S V8 396-454 engine-valve-spring

Data sheet

Position: Exhaust or Intake
Material: Chromium Silicon
Inside Diameter: 0.800 IN
Outside Diameter: 1.440 IN
Spring Type: Cylindrical
Camshaft Type: Hydraulic Flat Tappet
Coil Bind Height: 1.150 IN
Installed Height (in.): 1.88
Installed Pressure: 100 PSI
Open Height: 0.580 IN
Spring Rate (lbs./in.): N/A
Tubing Length: 300
Quantity: Set of 16
Damper Spring Included: No
Installed Height: 1.880 IN
Open Pressure: 300 P2
Springs Per Valve: Dual

Package dimensions

Width: 3.38 inch
Height: 2.25 inch
Depth: 12.25 inch
Weight: 4.00 lb
