V/S V8 262-400

Manufacturer: EDELBROCK
Part number: 5703
MPN: 5703
UPC: 085347057030
Availability:
£117.55
Tax included

Qty: 20, Delivery time: 8 working days

Description

The Edelbrock PN: 5703 Sure Seat Valve Spring for S/B Chevy O.E Cast iron cylinder heads are made of highest quality spring wire and precision wound to close tolerances, our Sure Seat Valve Spring sets are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. These are the same high-performance'springs used on Edelbrock Performer and RPM cylinder heads. For camshaft warranty compliance, use only the springs recommended by Edelbrock for each camshaft application.

Chevrolet:Small-Block Gen I:302 (4.9L)/327 (5.4L)/350 (5.7L)/400 (6.6L)

V/S V8 262-400 - Part number: EDL-5703 - for American Cars - delivery to the UK and the EU

Manufacturer part number: 5703 - V/S V8 262-400 engine-valve-spring

Data sheet

Position
Exhaust or Intake
Material
Chromium Silicon
Inside Diameter
0.878 IN
Outside Diameter
1.262 IN
Spring Type
Cylindrical
Camshaft Type
Hydraulic Flat Tappet
Coil Bind Height
1.160 IN
Installed Height (in.)
1.7
Installed Pressure
110 PSI
Open Height
1.210 IN
Spring Rate (lbs./in.)
N/A
Tubing Length
285
Quantity
Set of 16
Damper Spring Included
Yes
Installed Height
1.700 IN
Open Pressure
285 P2
Spring Rate
N/A
Springs Per Valve
Single

Package dimensions

Width: 3.38 inch
Height: 2.25 inch
Depth: 12.25 inch
Weight: 3.30 lb
