LS TIMING GEAR SET ADJ. 1X

Manufacturer: Summit Racing
Part number: G66451X005
MPN: G6645-1X-005
UPC: 190861246256
Availability: Out-of-Stock
£185.95
Tax included

Call to check: 0044 (0) 1933 225 564

Description

Timing Chain and Gear Set, Adjustable, Billet Steel, Single Roller, 3-Bolt, 1X, -0.005 in. Line Hone, LS, Kit

Summit Racing Pro LS Billet adjustable timing sets and gears provide maximum strength and reliability for your engine build. These single-row chains are precision-machined and available in standard, 0.005 under, and 0.010 under lengths for align-honed blocks. Summit Racing Pro LS Billet adjustable timing sets and gears work with 3-bolt performance cams and come in both 1x and 4x configurations to match any LS engine.

LS TIMING GEAR SET ADJ. 1X - Part number: SUM-G66451X005 - for American Cars - delivery to the UK and the EU

Manufacturer part number: G6645-1X-005 - LS TIMING GEAR SET ADJ. 1X engine-timing-chain

Data sheet

Gaskets Included
No
Quantity
Sold as a kit.
Tensioner Included
No
Thrust Bearing Included
No
Timing Chain Included
Yes
Timing Chain Style
Single roller
Camshaft Gear Attachment
3-bolt
Maximum Advance/Retard at Camshaft
8 degree
Maximum Advance/Retard at Crankshaft
4 degree
Cam Gear Included
Yes
Cam Gear Material
Billet aluminum
Crank Gear Included
Yes
Crank Gear Material
Billet steel
VVT Gear Included
No
Bolts/Studs Included
No
Offset Bushings Included
Yes
Special Attention
1x cam gear.

Package dimensions

Width: 20.00 inch
Height: 10.00 inch
Depth: 10.00 inch
Weight: 20.00 lb
