6.2L LS FORGED PISTON SET
Availability:
Out-of-Stock
Description
Pro LS 2618 Forged Piston, 4.080 bore, 1.326 C.H., 12cc Dish, Std. Stroke, Full Float Rod, NA/Boost/Nitrous, Cathedral/Rect. 6.2 LS3 L92 LS9, Set of 8
The Summit Racing Pro LS forged pistons are affordable and built to withstand the rigors of high boost and nitrous. These pistons are forged from Premium 2618 alloy - the strongest made. They have specially profiled piston skirts, which allow them to run a tight piston-to wall-clearance for maximum ring seal and minimal friction. They have many other high-tech features too!
The Summit Racing Pro LS forged pistons are affordable and built to withstand the rigors of high boost and nitrous. These pistons are forged from Premium 2618 alloy - the strongest made. They have specially profiled piston skirts, which allow them to run a tight piston-to wall-clearance for maximum ring seal and minimal friction. They have many other high-tech features too!
6.2L LS FORGED PISTON SET - Part number: SUM-326943408012 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 326943408012 - 6.2L LS FORGED PISTON SET engine-piston-ring-set
Data sheet
- Notes
- Designed to fit Cathedral and Rectangle port. Fits Gen 4 rods with 0.943 in. pin.
- Stroke
- 3.622 in.
- Quantity
- Sold as a set of 8.
- Rod Length
- 6.098 in.
- Piston Material
- Forged Aluminum
- Bore (mm)
- 103.630mm
- File Fit
- No
- Gapless
- No
- Wrist Pin Style
- Floating
- Bore (in.)
- 4.080 in.
- Piston Rings Included
- No
- Engine Stroke Type
- Stock
- Piston Style
- Dish, with two valve reliefs
- Piston Head Volume (cc)
- +12.00cc
- Wrist Pin Retainers Included
- Yes
- Wrist Pin Included
- Yes
- Pin Diameter (in)
- 0.943 in.
- Piston Ring Thickness
- 1.20mm x 1.20mm x 3.00mm
- Compression Height (in.)
- 1.326 in.
Package dimensions
Width: 10.00 inch
Height: 10.00 inch
Depth: 10.00 inch
Weight: 10.00 lb
