5.3L LS FORGED PISTON SET
Availability:
Out-of-Stock
Description
Pro LS 2618 Forged Pistons. 3.780 bore, 1.326 C.H., 2cc dome, Std. Stroke, .945 pin Press or Float, NA/Boost/Nitrous, Coated, 4.8L 5.3L Vortec Truck
The Summit Racing Pro LS forged pistons are affordable and built to withstand the rigors of high boost and nitrous. These pistons are forged from Premium 2618 alloy - the strongest made. They have specially profiled piston skirts, which allow them to run a tight piston-to wall-clearance for maximum ring seal and minimal friction. They have many other high-tech features too!
The Summit Racing Pro LS forged pistons are affordable and built to withstand the rigors of high boost and nitrous. These pistons are forged from Premium 2618 alloy - the strongest made. They have specially profiled piston skirts, which allow them to run a tight piston-to wall-clearance for maximum ring seal and minimal friction. They have many other high-tech features too!
5.3L LS FORGED PISTON SET - Part number: SUM-3269457802P - for American Cars - delivery to the UK and the EU
Manufacturer part number: 326945780-2P - 5.3L LS FORGED PISTON SET engine-piston-ring-set
Data sheet
- Notes
- Factory rods with 0.945 in. wrist pins are press fit only. 0.943 in. wrist pins are floating.
- Stroke
- 3.622 in.
- Quantity
- Sold as a set of 8.
- Rod Length
- 6.098 in.
- Piston Material
- Forged Aluminum
- Bore (mm)
- 96.010mm
- File Fit
- No
- Gapless
- No
- Wrist Pin Style
- Press-fit or floating
- Bore (in.)
- 3.780 in.
- Piston Rings Included
- No
- Piston Style
- Dome, with two valve reliefs
- Piston Head Volume (cc)
- -2.00cc
- Wrist Pin Retainers Included
- Yes
- Wrist Pin Included
- Yes
- Pin Diameter (in)
- 0.945 in.
- Piston Ring Thickness
- 1.50mm x 1.50mm x 3.00mm
- Compression Height (in.)
- 1.326 in.
Package dimensions
Width: 10.00 inch
Height: 10.00 inch
Depth: 10.00 inch
Weight: 10.00 lb
