LS RETRO CAST OIL PAN LP BLK
Availability:
Out-of-Stock
Description
Oil Pan, Engine Swap, Cast Aluminum, Black, 6.2 Quart Capacity, 3.60 in. Stroke Clearance, Chevy, LS, V8, Each
Swapping a GM LS based engine just got a lot easier! Summit Racing Pro LS cast aluminum oil pans are specifically designed to install an LS engine in a variety of GM musclecar and truck chassis. These pans offer OEM fitment, oil filter mounting, oil cooler provisions, and use OEM style gaskets. They are manufactured from cast aluminum to provided proper structural rigidity and heat dissipation. The pans include a baffle, oil pickup tube, sump plug, oil filter stud, and oil passage cover.
Swapping a GM LS based engine just got a lot easier! Summit Racing Pro LS cast aluminum oil pans are specifically designed to install an LS engine in a variety of GM musclecar and truck chassis. These pans offer OEM fitment, oil filter mounting, oil cooler provisions, and use OEM style gaskets. They are manufactured from cast aluminum to provided proper structural rigidity and heat dissipation. The pans include a baffle, oil pickup tube, sump plug, oil filter stud, and oil passage cover.
LS RETRO CAST OIL PAN LP BLK - Part number: SUM-121201B - for American Cars - delivery to the UK and the EU
Manufacturer part number: 121201B - LS RETRO CAST OIL PAN LP BLK engine-oil-pan
Data sheet
- Gaskets Included
- Yes
- Baffled
- Yes
- Hardware Included
- Yes
- Pickup Included
- Yes
- Windage Tray Included
- No
- Notes
- Oil pan capacity includes oil filter capacity. Will not fit the LS7 engine or engines with a stroke greater than 3.600 in. Requires use of LS3 dipstick (GM part number 12634547) and tube (GM part number 12625031).
- Quantity
- Sold individually.
- Dipstick Included
- No
- Sump Style
- Wet
- Stroker Clearanced
- No
- Maximum Stroke with OE Rod
- 3.600 in.
- Dipstick Provision
- No
- Sump Location
- Rear
- Oil Pan Capacity
- 6.20 quarts
- Oil Pan Depth (in)
- 5.500 in.
- Oil Pan Material
- Aluminum
- Oil Pan Finish
- Black powdercoated
- Kicked Out
- No
- Oil Pump Included
- No
- Oil Pump Driveshaft Included
- No
- Crank Scraper Included
- No
Package dimensions
Width: 40.00 inch
Height: 20.00 inch
Depth: 10.00 inch
Weight: 40.00 lb
