OIL PAN

Oil Pan, Steel, Clear Zinc, GM LS, Front Sump, Road Race Baffled Swap, Takes a Spin-On Oil Filter

Wet Sump, 6.5 Quart Capacity, 6 Deep, 14 Wide, 6.75 Long, Baffled Engine Application: GM LS Series Fits: LS Engine Conversions that require a Front Sump Oil Pan with a Spin-On Filter provision (Check Measurements)
-Oil pan has a thick precision laser cut steel rail with a clear zinc finish
-Clears 4.125 stroke with most steel rods
-Features a race proven diamond shape four trap door assembly and removable anti-slosh baffle that keeps oil contained in oil pump pick up area during Drifting, Road Racing and Drag Racing
-Oil Pan Design moves oil away from the rotating assembly for oil control and horsepower saving
-Accepts GM Part # 12558253 Windage Tray with modification
-Designed to be used with 2004-2006 Pontiac GTO O.E.M. Oil Pump Pick up, GM Part #12572654
-Features a detachable, billet aluminum Spin-On oil filter adapter with a 1/4in N.P.T. sensor port that accepts a 22 mm-1.5 thread Moroso Part No. 22463 or O.E.M. Spin-On oil filter
-Dipstick Fitting for required oil pan mounted dipstick
-Magnetic Drain Plug
PART # DESCRIPTION
20146 GM LS, Front Sump Swap, Race Baffled, Fully Fabricated, Steel, Oil Pan REQUIRES THE FOLLOWING GM PARTS TO COMPLETE THE INSTALLATION OF PART NO. 20146 ON ENGINE GM PART DESCRIPTION 12572654 Oil Pump Pick Up 12558253 Windage Tray with modification PART# AVAILABLE OPTIONS 22120 Oil Pump GM LS, Race 25970 Universal Dipstick Kit 25971 Universal Dipstick Kit, Braided Stainless Flex Tube 25973 Universal Dipstick Kit, Twist Lock 38541 Oil Pan Mounting Stud Kit. 74162` Dust Shield, GM LS 93152 Oil Pan Gasket, GM LS
