INTAKE MANIFOLD SBC PERF TBI

Manufacturer: EDELBROCK

Part number: 3704

MPN: 3704

UPC: 085347037049

Availability: Out-of-Stock

£554.95

Tax included

Call to check: 0044 (0) 1933 225 564

Description

Edelbrock part PN: 3704 Performer T.B.I. intake manifold is designed for 1987-95 305/350 c.i.d. 5.0/5.7L Chevy throttle body injected (T.B.I.) engines. Accepts all OEM equipment and small-bore (1-11/16in.) throttle body injectors only. Computer chip is supplied free of charge with proof of purchase of intake manifold, cam and heads. Will not fit Caprice or Buick and Cadillac 'B' bodies.

Chevrolet:Small-Block Gen I:305 (5.0L)/350 (5.7L)

INTAKE MANIFOLD SBC PERF TBI - Part number: EDL-3704 - for American Cars - delivery to the UK and the EU

Manufacturer part number: 3704 - INTAKE MANIFOLD SBC PERF TBI engine-intake-manifold

Data sheet

Position: N/A
Engine Make/Size: Chevy Small Block (262-400)
Emission: With EGR
Finish: Satin
Material: Aluminum
Usage: Street/Hi-Performance
Cylinder Head Type: Standard
RPM Range: Idle -5500
Number Of Carbs: None; For Fuel Injection
Gasket Or Seal Included: No
Grade Type: Performance
Center Maximum Height: 4.400 IN
CNC Ported: No
Front Maximum Height: 3.700 IN
Rear Maximum Height: 5.100 IN
Single Or Dual Plane Type: Dual Plane

Package dimensions

Width: 10.60 inch
Height: 5.50 inch
Depth: 22.50 inch
Weight: 19.40 lb
