MANIFOLD BBC SV 565 .070 THICK FLANGE SHORT DECK
Availability:
Out-of-Stock
Description
Edelbrock part PN: 2895 Super Victor II intake manifold is designed for use with large cubic inch big-block Chevy engines using the latest design conventional port heads. This single-plane intake manifold is ideal for any 1,000+ horsepower drag race engine with high air flow requirements. This manifold features thicker flanges resulting with .080in. increase in port exit height. Accepts standard height distributors. The Edelbrock Super Victor II PN: 2895 intake manifold has an extra large carburetor outer flange with a 5in. x 5in. opening to fit high flow carburetors and throttle stops.
Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L)
Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L)
MANIFOLD BBC SV 565 .070 THICK FLANGE SHORT DECK - Part number: EDL-2895 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 2895 - MANIFOLD BBC SV 565 .070 THICK FLANGE SHORT DECK engine-intake-manifold
Data sheet
- Position
- N/A
- Engine Make/Size
- Chevy Big Block (396-502)
- Emission
- Without EGR
- Finish
- Satin
- Material
- Aluminum
- Usage
- Racing
- Cylinder Head Type
- Rectangular Port
- RPM Range
- 3500-8500
- Number Of Carbs
- One
- Gasket Or Seal Included
- No
- Grade Type
- Performance
- Center Maximum Height
- 7.620 IN
- CNC Ported
- No
- Front Maximum Height
- 7.620 IN
- Rear Maximum Height
- 7.620 IN
- Single Or Dual Plane Type
- Single Plane
Package dimensions
Width: 15.75 inch
Height: 9.00 inch
Depth: 22.25 inch
Weight: 28.00 lb
