Description
Edelbrock part PN: 28542 BV3 CNC intake manifold is designed for Edelbrock BV3 cylinder heads which have a unique symmetrical port layout for the 4.84in. bore spacing Big Block Chevrolet. This manifold features a spider style single-plane design with efficient runners that are engineered to deliver peak performance across a wide range of applications. The manifold has a lengthened plenum and a narrowed runner design to deliver equal length runners. This manifold is also the first in the Big Victor Series to feature Edelbrock's unique two-piece design. This unique design simplifies and reduces time in applications that require CNC porting. The manifold is cast in two separate pieces, allowing them to be taken apart for better porting access and then they can be bolted back together while maintaining a perfect match. Each piece has a precision machined o-ring groove to ensure a proper seal. High quality bolts and washers are supplied. The manifold also has a matching valley plate with the proper flange thickness (sold separately). This unique valley plate features a highly efficient integrated water distribution system, reducing the need for external plumbing. The manifold features a carb pad with a 4500 Series flange that is also large enough to accommodate various throttle body and throttle stop applications on the market today.
Chevrolet:Big-Block Race
MANIFOLD BIG VICTOR 3 (BV3) 4.84in. BORE SPACING STD BBC W/EDELBROCK BIG VICTOR - Part number: EDL-28549 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 28549 - MANIFOLD BIG VICTOR 3 (BV3) 4.84in. BORE SPACING STD BBC W/EDELBROCK BIG VICTOR engine-intake-manifold
Data sheet
- Position
- N/A
- Engine Make/Size
- Chevy Big Block (396-502)
- Emission
- Without EGR
- Finish
- Satin
- Material
- Aluminum
- Usage
- Racing
- Cylinder Head Type
- Rectangular Port
- RPM Range
- N/A
- Number Of Carbs
- One
- Gasket Or Seal Included
- No
- Grade Type
- Performance
- Center Maximum Height
- 0.010 IN
- CNC Ported
- No
- Front Maximum Height
- 0.010 IN
- Rear Maximum Height
- 0.010 IN
- Single Or Dual Plane Type
- Single Plane
Package dimensions
Width: 16.31 inch
Height: 9.38 inch
Depth: 23.19 inch
Weight: 29.00 lb
