Description
The Edelbrock PN: 2036 RPM Dual-Quad manifold and carb kit is designed for 390-428 Big-Block Ford FE applications. A huge hit among street rodders, this Dual-Quad Kits offer the ultimate set-up for anyone who wants the look and the performance of dual-quad carbs. The Edelbrock PN: 2036 includes an Edelbrock RPM or RPM Air-Gap Dual-Quad intake manifold and two 500 cfm Thunder Series AVS carburetors calibrated specifically for dual-quad applications (one manual choke, one electric choke). To make the installation simple, these kits also include our high-tech progressive throttle linkage, Russell fuel inlet, high-quality Edelbrock intake gaskets, intake bolt set and carburetor stud kit. The manifold and Thunder Series carbs are available with a standard satin finish or with our bright EnduraShine chrome-like finish for long lasting show quality looks.
Ford:FE:390 (6.4L)/406 (6.6L)/410 (6.7L)/427 (7.0L)/428 (7.0L)
MANIFOLD/CARB KIT DUAL QUAD RPM AIR GAP 390-428 FE FORD - Part number: EDL-2036 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 2036 - MANIFOLD/CARB KIT DUAL QUAD RPM AIR GAP 390-428 FE FORD engine-intake-manifold-carburetor-kit
Data sheet
- Engine Make/Size
- Ford 390-428
- Carburetor Type
- (2) AVS2 Series 500 cfm
- Finish
- Satin
- Cylinder Head Type
- Standard
- Family
- RPM Air-Gap
- Series
- RPM Air-Gap
- Single Or Dual Plane Type
- Dual
- Base Plate Gasket Mount Hole Quantity
- 8
- Base Plate Gasket Thickness
- 0.048 IN
- Base Plate Material
- Aluminum
- Intake Manifold Type
- RPM Air-Gap
Package dimensions
Width: 13.75 inch
Height: 13.87 inch
Depth: 25.00 inch
Weight: 52.00 lb
