- Out-of-Stock
Edelbrock Chevy Gen V, LT4 Cylinder Head
Availability:
Out-of-Stock
Description
The Edelbrock PN: 77279 is a street performance cylinder head for the Gen V LT4 engine. This head features the same architecture as the factory LT4 head but with a thicker deck, thicker exhaust/intake port walls, CNC'd chambers, CNC blended valve seats and intake/exhaust gasket match for improved flow characteristics.
Chevrolet:Small-Block Gen V LT4:376 (6.2L)
Chevrolet:Small-Block Gen V LT4:376 (6.2L)
Edelbrock Chevy Gen V, LT4 Cylinder Head - Part number: EDL-77279 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 77279 - Edelbrock Chevy Gen V, LT4 Cylinder Head engine-cylinder-head
Data sheet
- Material
- Aluminum
- Grade Type
- Performance
- Camshaft Type
- Hydraulic Roller
- Family
- Performer RPM
- Series
- Performer RPM
- CNC Ported
- Yes
- Combustion Chamber Volume
- 64 CCM
- Construction Type
- Complete
- Deck Thickness
- 0.7500 IN
- EGR Port
- No
- Guide Plates Included
- No
- Quantity
- Sold Individually
- Retainer Included
- Yes
- Valve Included
- Yes
- Valve Springs Included
- Yes
- Head Casting Number
- N/A
- Horsepower
- 600+ HJ
- Exhaust Port Location
- Standard
- Exhaust Runner Volume
- 115 CCM
- Exhaust Valve Diameter
- 1.60 IN
- Guide Material
- Manganese Bronze
- Intake Runner Volume
- 305 CCM
- Intake Valve Diameter
- 2.165 IN
- Seat Angle
- Exhaust 45 deg/Intake 45 DD
- Seat Material
- Ductile Iron
- Valve Spring Diameter
- 1.32 IN
- Valve Spring Maximum Lift
- 0.650 IN
- Valve Stem Diameter
- 0.314961 IN
Package dimensions
Width: 11.88 inch
Height: 8.75 inch
Depth: 23.00 inch
Weight: 60.00 lb
