CYL HEAD CHEVY GEN V LT1 PERF RPM COMPLETE
Availability:
Out-of-Stock
Description
The Edelbrock part PN: 77119 LT1 (Gen V) Performance RPM cylinder head is ideal for street engines and are engineered to be a great high-performance upgrade for stock GM Gen V LT1 engines. It has been designed with a thicker deck and more material in the intake, exhaust and port walls for improved strength and durability. This cylinder head features CNC machined chambers as well as CNC blended valve seats, intake and exhaust ports for consistency. They have been designed with high flow intake, exhaust ports and back cut intake valves for improved air flow. The valve position has also been revised to accommodate interlocking valve seat rings and larger valves. The Performer RPM retains the stock rocker arm, intake/exhaust ports and spark plug location for use with factory components. Like all the other cylinder head, this has been designed, tested and cast from 356 aluminum and heat treated to T-6 specs in our facilities in Southern California to guarantee you get the best from a name you can trust.,Combustion chamber volume: 58cc,Intake runner volume: 305cc,Exhaust runner volume: 115cc,Intake valve diameter: 2.165in.,Exhaust valve diameter: 1.600in.
Chevrolet:Small-Block Gen V LT1:376 (6.2L)
Chevrolet:Small-Block Gen V LT1:376 (6.2L)
CYL HEAD CHEVY GEN V LT1 PERF RPM COMPLETE - Part number: EDL-77119 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 77119 - CYL HEAD CHEVY GEN V LT1 PERF RPM COMPLETE engine-cylinder-head
Data sheet
- Type
- Complete
- Engine Make/Size
- Chevy LT1
- Emission
- Non-Emissions
- Finish
- Cast
- Material
- Aluminum
- Usage
- Street/Hi-Performance
- Cylinder Head Type
- Standard
- Grade Type
- Performance
- Preparation
- Bolt On (Not Required)
- Camshaft Type
- Hydraulic Roller
- Family
- Performer RPM
- Series
- Performer RPM
- CNC Ported
- Yes
- Combustion Chamber Volume
- 61 CCM
- Construction Type
- Complete
- Deck Thickness
- 0.7500 IN
- EGR Port
- No
- Guide Plates Included
- No
- Quantity
- Sold Individually
- Retainer Included
- Yes
- Valve Included
- Yes
- Valve Springs Included
- Yes
- Head Casting Number
- N/A
- Horsepower
- 600+ HJ
- Exhaust Port Location
- Standard
- Exhaust Runner Volume
- 115 CCM
- Exhaust Valve Diameter
- 1.60 IN
- Guide Material
- Manganese Bronze
- Intake Runner Volume
- 305 CCM
- Intake Valve Diameter
- 2.165 IN
- Seat Angle
- Exhaust 45 deg/Intake 45 DD
- Seat Material
- Ductile Iron
- Valve Angle
- Exhaust 11.8 X 1 deg/Intake 12 x 4 DD
- Valve Spring Diameter
- 1.32 IN
- Valve Spring Maximum Lift
- 0.650 IN
- Valve Stem Diameter
- 0.314961 IN
Package dimensions
Width: 10.13 inch
Height: 7.19 inch
Depth: 22.19 inch
Weight: 24.85 lb
