CYL HEAD PERF LT1 SBC SINGLE BARE FOR NHRA SUPER STOCK

Manufacturer: EDELBROCK
Part number: 61917
MPN: 61917
UPC: 085347619177
Availability: Out-of-Stock
£0.00
Tax included

Call to check: 0044 (0) 1933 225 564

Description

The Edelbrock part PN: 61917 small-block Chevy LT1 (1992-97) Performer NHRA cylinder heads deliver 24 horsepower over stock and raise the peak power level by 500 rpm. These heads are designed to accept factory style self-aligning rockers. Performer LT1 cylinder heads are 50-state street legal and accept factory center bolt valve covers. They feature exhaust ports in the stock location for use with stock or aftermarket exhaust manifolds and headers. Match with RPM Air-Gap intake PN: 7107, throttle body PN: 3809 and camshaft PN: 2108 for the Total Power Package combo.,61917 Cylinder Heads are allowed for use in the NHRA Super Stock class,Combustion chamber volume: 54cc,Intake runner volume: 170cc,Exhaust runner volume: 60cc,Intake valve diameter: 1.94in.,Exhaust valve diameter: 1.55in.

Chevrolet:Small-Block Gen II LT1:350 (5.7L)

CYL HEAD PERF LT1 SBC SINGLE BARE FOR NHRA SUPER STOCK - Part number: EDL-61917 - for American Cars - delivery to the UK and the EU

Manufacturer part number: 61917 - CYL HEAD PERF LT1 SBC SINGLE BARE FOR NHRA SUPER STOCK engine-cylinder-head

Data sheet

Type
Standard
Engine Make/Size
Chevy LT1
Emission
Non-Emissions
Finish
Aluminum
Material
Aluminum
Usage
Competition
Cylinder Head Type
Standard
Grade Type
Performance
Preparation
Requires Professional Preparation (Bare)
CNC Ported
No
Combustion Chamber Volume
54.0 CCM
Deck Thickness
0.625 IN
Guide Plates Included
No
Head Casting Number
6190F
Intake Runner Volume
170.0 CCM
Push Rod Diameter
0.312 IN
Rocker Stud Diameter
0.375 IN
Valve Angle
23 DD
Deck Height
9.025 IN

Package dimensions

Width: 10.44 inch
Height: 7.38 inch
Depth: 22.75 inch
Weight: 24.85 lb
