CYL HEAD BBC PRO PORT VICTOR HIGH PORT CONVENTIONAL DR-23 HIP d PRO PORT RAW
Availability:
Out-of-Stock
Description
The Victor BV3 Cylinder Head PN: 614469 for Chevy Big-Block engines is Edelbrock’s third generation of the Victor Chevy BB head. This bare cylinder head has a race-oriented design for those who demand a high-performance head with durability that they can rely on. For those who wish to do their own port work, Edelbrock offers the BV3 Head PN: 614669. Both the DR23 and BV3 are manufactured with special small-run production methods for the highest quality results. This includes Hot Isostatic Press processing in which raw aluminum castings are heated to 900 degrees Fahrenheit in a pressurized chamber with up to 30,000 PSI. This eliminates imperfections by removing any trapped gases or internal porosity. The result is an incredibly strong, dense sand casting that has three times the fatigue life and nearly the consistency of billet aluminum. HIP-processed heads have less chance of failure due to fatigue and also provide a smoother machined surface when port and chamber work is applied.
Chevrolet:Big-Block Race
Chevrolet:Big-Block Race
CYL HEAD BBC PRO PORT VICTOR HIGH PORT CONVENTIONAL DR-23 HIP d PRO PORT RAW - Part number: EDL-614469 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 614469 - CYL HEAD BBC PRO PORT VICTOR HIGH PORT CONVENTIONAL DR-23 HIP d PRO PORT RAW engine-cylinder-head
Data sheet
- Type
- Bare
- Engine Make/Size
- Chevy Big Block (396-502)
- Emission
- Non-Emissions
- Finish
- Cast Aluminum
- Material
- Aluminum
- Usage
- Racing
- Cylinder Head Type
- Standard
- Grade Type
- Performance
- Preparation
- Requires Professional Preparation (Bare)
- Family
- Victor
- Series
- Pro-Port
- CNC Ported
- No
- Combustion Chamber Volume
- N/A
- Construction Type
- Pro-Port Raw
- Deck Thickness
- 0.5625 IN
- EGR Port
- No
- Guide Plates Included
- No
- Quantity
- Sold Individually
- Retainer Included
- No
- Valve Included
- No
- Valve Springs Included
- No
- Head Casting Number
- N/A
- Exhaust Valve Diameter
- (Suggested) 1.94 IN
- Guide Material
- Manganese Bronze
- Intake Valve Diameter
- (Suggested) 2.42 IN
- Seat Angle
- Exhaust 45 deg/Intake 45 DD
- Seat Material
- Ductile Iron
- Valve Angle
- 23 DD
- Specialty
- Hot Isostatic Pressing (HIP) Processing
- Exhaust Port Entry
- 2.10 in x 1.80 IN
- Exhaust Valve Pierce Points (X,Y)(C)
- 1.150 in, -0.580 IN
- Intake Port Entry
- 1.80 in x 2.56 IN
- Intake Valve Pierce Points (X,Y)(C)
- -0.827 in, 0.227 IN
- Valve Guides Included
- Yes
- Valve Seats Included
- Yes
Package dimensions
Width: 9.00 inch
Height: 12.13 inch
Depth: 26.50 inch
Weight: 70.00 lb
