- Out-of-Stock
CYL HEAD (NR) BBC PERF RPM 348/409ci FOR HYD ROLLER CAM COMPLETE POLISHED
Availability:
Out-of-Stock
Description
The Edelbrock PN: 608115 Performer RPM cylinder head is designed for 1958-1965 Chevrolet 'W' Series 348/409 big-block applications. The Edelbrock PN: 608115 Performer RPM head is perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. This cylinder head delivers great throttle response and power from 1500 to 6500 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only.
Chevrolet:W Big-Block:348 (5.7L)/409 (6.7L)
Chevrolet:W Big-Block:348 (5.7L)/409 (6.7L)
CYL HEAD (NR) BBC PERF RPM 348/409ci FOR HYD ROLLER CAM COMPLETE POLISHED - Part number: EDL-608115 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 608115 - CYL HEAD (NR) BBC PERF RPM 348/409ci FOR HYD ROLLER CAM COMPLETE POLISHED engine-cylinder-head
Data sheet
- Type
- Complete
- Engine Make/Size
- Chevy Big Block (396-502)
- Emission
- Non-Emissions
- Finish
- Polished
- Material
- Aluminum
- Usage
- Street/Performance
- Cylinder Head Type
- Standard
- Grade Type
- Performance
- Preparation
- Bolt On (Not Required)
- Camshaft Type
- Hydraulic Roller
- Family
- Performer RPM
- Series
- Performer RPM
- CNC Ported
- Yes
- Combustion Chamber Volume
- 16 CCM
- Construction Type
- Complete
- Deck Thickness
- 0.5625 IN
- EGR Port
- No
- Guide Plates Included
- Yes
- Quantity
- Sold Individually
- Retainer Included
- Yes
- Valve Included
- Yes
- Valve Springs Included
- Yes
- Head Casting Number
- N/A
- Horsepower
- 400-600 HJ
- Exhaust Port Location
- Standard
- Exhaust Runner Volume
- 115 CCM
- Exhaust Valve Diameter
- 1.72 IN
- Guide Material
- Manganese Bronze
- Guide Plate Material
- Hardened Steel
- Intake Runner Volume
- 220 CCM
- Intake Valve Diameter
- 2.19 IN
- Push Rod Diameter
- (Suggested) 0.375 IN
- Rocker Stud Diameter
- 0.4375 IN
- Seat Angle
- Exhaust 45 deg/Intake 45 DD
- Seat Material
- Ductile Iron
- Valve Angle
- 0 DD
- Valve Spring Diameter
- 1.55 IN
- Valve Spring Maximum Lift
- 0.650 IN
- Valve Stem Diameter
- 0.3438 IN
- Spark Plug Hex Size
- 14 MM
- Spark Plug Reach
- 0.750 IN
- Spark Plug Seat Type
- Flat
- Spark Plug Thread Diameter
- 14 MM
Package dimensions
Width: 11.00 inch
Height: 9.00 inch
Depth: 26.00 inch
Weight: 34.60 lb
