PERF OLDS COMP HEAD
Availability:
Out-of-Stock
Description
The Edelbrock PN: 60519 Performer RPM cylinder head is designed for 1965-76 Oldsmobile 400, 425 &455 c.i.d. V8 applications. The Edelbrock PN: 60519 Performer RPM head is perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. This cylinder head delivers great throttle response and power from 1500 to 6500 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only.
Oldsmobile:Big-Block:400 (6.6L)/425 (7.0L)/455 (7.5L)
Oldsmobile:Big-Block:400 (6.6L)/425 (7.0L)/455 (7.5L)
PERF OLDS COMP HEAD - Part number: EDL-60519 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 60519 - PERF OLDS COMP HEAD engine-cylinder-head
Data sheet
- Type
- Complete
- Engine Make/Size
- Olds 400-455
- Emission
- Non-Emissions
- Finish
- Cast Aluminum
- Material
- Aluminum
- Usage
- Street/Hi-Performance
- Cylinder Head Type
- Standard
- Grade Type
- Performance
- Preparation
- Bolt On (Not Required)
- Camshaft Type
- Flat Tappet
- Family
- Performer RPM
- Series
- Performer RPM
- CNC Ported
- No
- Combustion Chamber Volume
- 77 CCM
- Construction Type
- Complete
- Deck Thickness
- 0.625 IN
- EGR Port
- No
- Guide Plates Included
- Yes
- Quantity
- Sold Individually
- Retainer Included
- Yes
- Valve Included
- Yes
- Valve Springs Included
- Yes
- Head Casting Number
- N/A
- Horsepower
- 450-550 HJ
- Exhaust Port Location
- Standard
- Exhaust Runner Volume
- 106 CCM
- Exhaust Valve Diameter
- 1.680 IN
- Guide Material
- Manganese Bronze
- Guide Plate Material
- Hardened Steel
- Intake Runner Volume
- 188 CCM
- Intake Valve Diameter
- 2.072 IN
- Push Rod Diameter
- (Suggested) 0.375 IN
- Rocker Stud Diameter
- 0.4375 IN
- Seat Angle
- Exhaust 45 deg/Intake 45 DD
- Seat Material
- Ductile Iron
- Valve Angle
- 6 DD
- Valve Spring Diameter
- 1.46 IN
- Valve Spring Maximum Lift
- 0.575 IN
- Valve Stem Diameter
- 0.3438 IN
Package dimensions
Width: 11.10 inch
Height: 8.90 inch
Depth: 25.90 inch
Weight: 35.75 lb
