POLISHED PERF OLDS COMP HEAD
Availability:
Out-of-Stock
Description
The Edelbrock PN: 605119 Performer RPM cylinder heads are designed for 1965-76 Oldsmobile 400, 425 &455 c.i.d. V8 applications. The Edelbrock PN: 605119 Performer RPM heads are perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. These cylinder heads deliver great throttle response and power from 1500 to 6500 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only.
Oldsmobile:Big-Block:400 (6.6L)/425 (7.0L)/455 (7.5L)
Oldsmobile:Big-Block:400 (6.6L)/425 (7.0L)/455 (7.5L)
POLISHED PERF OLDS COMP HEAD - Part number: EDL-605119 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 605119 - POLISHED PERF OLDS COMP HEAD engine-cylinder-head
Data sheet
- Type
- Complete
- Engine Make/Size
- Olds 400-455
- Emission
- Non-Emissions
- Finish
- Polished
- Material
- Aluminum
- Usage
- Street/Performance
- Cylinder Head Type
- Standard
- Grade Type
- Performance
- Preparation
- Bolt On (Not Required)
- CNC Ported
- No
- Combustion Chamber Volume
- 77.0 CCM
- Deck Thickness
- 0.625 IN
- Guide Plates Included
- Yes
- Head Casting Number
- 31-6051
- Exhaust Valve Diameter
- 1.680 IN
- Guide Plate Material
- Hardened Steel
- Intake Runner Volume
- 188.0 CCM
- Intake Valve Diameter
- 2.072 IN
- Push Rod Diameter
- 0.375 IN
- Valve Angle
- 6 DD
- Valve Spring Diameter
- 1.460 IN
- Valve Spring Maximum Lift
- 0.575 IN
- Valve Stem Diameter
- 0.341 IN
- Deck Height
- 9.8 IN
Package dimensions
Width: 11.00 inch
Height: 8.50 inch
Depth: 26.10 inch
Weight: 35.60 lb
