CAMSHAFT LS
Availability:
Out-of-Stock
Description
Summit Factory Performance Stage 3 LS Single Plane Cam, 236/246 110 +0 .612/.612 Lift, LS1 LS2 LS6 LS3 LQ9, Summit's version of Factory LSX 454 cam
The Summit Racing Pro LS Single Plane cams are affordable and designed for racing applications where a carburetor and open exhaust are commonly found. These cams have slightly narrower lobe separation to increase torque and compliment short runner intakes. They come in distinct cam timing increments to give you maximum control over the power band. They're also designed with longevity in mind by taking stress off the valve train. These lobes remain stable to over 7,000 rpm with a common .600 and .670 lift dual spring kits.
The Summit Racing Pro LS Single Plane cams are affordable and designed for racing applications where a carburetor and open exhaust are commonly found. These cams have slightly narrower lobe separation to increase torque and compliment short runner intakes. They come in distinct cam timing increments to give you maximum control over the power band. They're also designed with longevity in mind by taking stress off the valve train. These lobes remain stable to over 7,000 rpm with a common .600 and .670 lift dual spring kits.
CAMSHAFT LS - Part number: SUM-8702 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 8702 - CAMSHAFT LS engine-camshaft
Data sheet
- Quantity
- Sold individually.
- Advertised Exhaust Duration
- 309
- Advertised Intake Duration
- 298
- Exhaust Valve Lift with Factory Rocker Arm Ratio
- 0.612 in.
- Intake Valve Lift with Factory Rocker Arm Ratio
- 0.612 in.
- Basic Operating RPM Range
- 2,500-6,500
- Valve Springs Required
- Yes
- Cam Style
- Hydraulic roller tappet
- Camshaft Gear Attachment
- 3-bolt
- Intake Duration at 050 inch Lift
- 236
- Exhaust Duration at 050 inch Lift
- 246
- Duration at 050 inch Lift
- 236 int./246 exh.
- Advertised Duration
- 298 int./309 exh.
- Lobe Separation (degrees)
- 110
- Computer-Controlled Compatible
- Yes
- Camshaft Manufacturers Description
- The Summit Stage 3 Single Plane cam has an aggressive lope with very strong mid-range and top end. If you are looking for maximum power through the 3500-6800 rpm range, this cam is for you. Fly-cutting pistons may be required.
- Valve Lift with Factory Rocker Arm Ratio
- 0.612 int./0.612 exh.
Package dimensions
Width: 25.00 inch
Height: 10.00 inch
Depth: 10.00 inch
Weight: 12.00 lb
