SBC RPM CAM KIT
Availability:
Qty: 30, Delivery time: 8 working days
Description
Edelbrock part PN: 7102 Performer RPM Camshaft is designed for 1957-1986 small-block Chevy 283-400 V-8 applications. This Edelbrock cam kit produced 410 HP & 408 ft-lbs. of torque when used with PN: 7501 intake and PN: 60899 cylinder heads on a 350 engine. The camshaft works well with high-performance's street applications, Performer RPM cams provide power from 1500 to 6500 rpm. This hydraulic lifter camshaft is dyno-matched to Performer RPM manifolds for high-rpm horsepower while still maintaining acceptable low-end torque. With 10 to 12 inches of manifold vacuum at idle, Performer RPM cams have more lift and duration than most street camshafts. Hydraulic flat tappet lifters are included with each Performer RPM camshaft., Camshaft Specifications:,Duration @ .050 Intake: 234 degrees ,Duration @ .050 Exhaust: 244 degrees,Lift @ Valve Intake: .488in.,Lift @ Valve Exhaust: .510in.,Lobe Separation: 112 Degrees,Intake Centerline: 107 Degrees,Idle Vacuum @ 1000 RPM's: 11in.
Chevrolet:Small-Block Gen I:302 (4.9L)/327 (5.4L)/350 (5.7L)/400 (6.6L)
Chevrolet:Small-Block Gen I:302 (4.9L)/327 (5.4L)/350 (5.7L)/400 (6.6L)
SBC RPM CAM KIT - Part number: EDL-7102 - for American Cars - delivery to the UK and the EU
Manufacturer part number: 7102 - SBC RPM CAM KIT engine-camshaft-and-lifter-kit
Data sheet
- Engine Make/Size
- Chevy Small Block (262-400)
- Usage
- Street/Performance
- RPM Range
- 1000-7000
- Grade Type
- Performance
- Lifter Type
- Hydraulic
- Exh. Duration @ .050 in. (Deg)
- 244
- Exh. Duration Advertised (Deg)
- 318
- Exhaust Valve Lift
- 0.510 IN
- Intake Duration @ 0.050 in.
- 234 Degree
- Intake Duration Advertised
- 308
- Intake Valve Lift
- 0.488 IN
- Cam Type
- Cast
- Advertised Exhaust Duration
- 318 DD
- Advertised Intake Duration
- 308 DD
- Computer Controlled Compatible
- No
- Exhaust Duration at .050 inch Lift
- 244 DD
- Intake Duration .050 Inch Lift
- 234 DD
- Lifter Materials
- Hardened Steel
- Lobe Separation
- 112 DD
Package dimensions
Width: 10.50 inch
Height: 3.80 inch
Depth: 26.50 inch
Weight: 13.75 lb
